| Model | V(max) Volts |
I(max) Amps |
I(hold) | I(hold) | Resistance | Max.Time To Trip | Tripped Power Dissipation |
||
| Amepres at 23℃ |
Ohms at 23℃ |
Amepres at 23℃ |
Seconds at 23℃ |
Watts at 23℃ |
|||||
| Hold | Trip | R(min) | R1(max) | Typ | |||||
| MF-NSMF012 | 30 | 10 | 0.12 | 0.29 | 1.35 | 8.50 | 1.0 | 0.2 | 0.4 |
| MF-NSMF020 | 24 | 10 | 0.20 | 0.46 | 0.60 | 2.60 | 1.0 | 0.6 | 0.6 |
| MF-NSMF020X | 30 | 60 | 0.20 | 0.40 | 0.60 | 3.30 | 1.0 | 0.6 | 0.6 |
| MF-NSMF035 | 6 | 100 | 0.35 | 0.75 | 0.30 | 1.20 | 8.0 | 0.1 | 0.6 |
| MF-NSMF035X | 16 | 20 | 0.35 | 0.75 | 0.30 | 1.40 | 3.5 | 0.1 | 0.6 |
| MF-NSMF050 | 13 | 100 | 0.50 | 1.00 | 0.15 | 0.70 | 8.0 | 0.1 | 0.6 |
| MF-NSMF075 | 6 | 100 | 0.75 | 1.50 | 0.10 | 0.40 | 8.0 | 0.1 | 0.4 |
| MF-NSMF110 | 6 | 100 | 1.10 | 2.20 | 0.06 | 0.20 | 8.0 | 0.1 | 0.4 |
| MF-NSMF150 | 6 | 100 | 1.50 | 3.00 | 0.03 | 0.13 | 8.0 | 0.3 | 0.6 |
| MF-NSMF200 | 6 | 100 | 2.00 | 4.00 | 0.02 | 0.09 | 8.0 | 1.0 | 0.7 |
