| Model | V(max) Volts | I(max) Amps | I(hold) | I(hold) | Resistance | Max.Time To Trip | Tripped Power Dissipation |
||
| Amepres at 23℃ | Ohms at 23℃ | Amepres at 23℃ |
Seconds at 23℃ |
Watts at 23℃ |
|||||
| Hold | Trip | R(min) | R1(max) | Typ | |||||
| MF-FSMF010X | 15 | 40 | 0.10 | 0.30 | 0.90 | 6.00 | 0.5 | 1.0 | 0.5 |
| MF-FSMF020X | 9 | 40 | 0.20 | 0.50 | 0.55 | 3.50 | 1.0 | 0.6 | 0.5 |
| MF-FSMF035X | 6 | 40 | 0.35 | 0.75 | 0.20 | 1.40 | 8.0 | 0.1 | 0.5 |
| MF-FSMF050X | 6 | 40 | 0.50 | 1.00 | 0.10 | 0.80 | 8.0 | 0.1 | 0.5 |
