Benefits
• Smaller size saves board space and cost
• Many product choices give engineers more design
flexibility
• Compatible with high-volume electronics assembly
• Assists in meeting regulatory requirements
• Higher voltage ratings allow use in new applications
Features
• RoHS compliant
• Halogen free (refers to: Br≤900ppm, Cl≤900ppm, Br+Cl≤1500ppm)
• Broadest range of resettable devices available in the industry
• Current ratings from 0.05 to 3A
• Voltage ratings from 6V computer and electronic applications to 60V telecom applications
• Agency recognition: UL, CSA, TÜV
• Small footprint
• Fast time-to-trip
• Low resistance
Electrical Characteristics
| Part Number |
IH (A) |
IT (A) |
VMAX (VDC) |
IMAX (A) |
PD MAX (W) |
Max.Time-to-Trip |
RMIN (Ω) |
R1MAX(Ω) |
| (A) |
(S) |
| nanoSMDC012F |
0.12 |
0.39 |
48 |
10 |
0.50 |
1.00 |
0.20 |
1.40 |
6.50 |
| nanoSMDC016F |
0.16 |
0.45 |
48 |
10 |
0.50 |
1.00 |
0.30 |
1.10 |
5.00 |
| nanoSMDC020F |
0.20 |
0.42 |
24 |
100 |
0.60 |
8.00 |
0.10 |
0.65 |
3.10 |
| nanoSMDC025F |
0.25 |
0.58 |
16 |
100 |
0.60 |
8.00 |
0.01 |
0.55 |
2.30 |
| nanoSMDC035F |
0.35 |
0.75 |
16 |
20 |
0.80 |
3.50 |
0.10 |
0.45 |
1.35 |
| nanoSMDC050F/13.2 |
0.50 |
1.10 |
13.2 |
100 |
0.80 |
8.00 |
0.10 |
0.20 |
0.75 |
| nanoSMDC075F |
0.75 |
1.50 |
6 |
100 |
0.80 |
8.00 |
0.10 |
0.09 |
0.30 |
| nanoSMDC110F |
1.10 |
2.20 |
6 |
100 |
0.80 |
8.00 |
0.10 |
0.07 |
0.20 |
| nanoSMDC150F |
1.50 |
3.00 |
6 |
100 |
0.80 |
8.00 |
0.30 |
0.04 |
0.11 |
| nanoSMDC200F |
2.00 |
4.00 |
6 |
100 |
1.00 |
8.00 |
1.50 |
0.02 |
0.07 |
